Offer 377298
CIVIEMME ST 420/100 HS from 2007
Stackers
Offer Details
| Offer Number: | 377298 |
|---|---|
| Brand: | CIVIEMME |
| Model: | ST 420/100 HS |
| Manufacturer | CIVIEMME |
| Condition: | Good |
| Year: | 2007 |
| Incoterm: | |
| Cylinders Condition: | |
| Under Power: | Yes |
| Still in production: | Yes |
| Test possible: | Yes |
| Complete and in working condition: | Yes |
| Availability: | |
| Counter: | |
| Machine number: | |
| Description: | * completely rebuilt mechanically and electronically with new PLC and software<>1 RIGHT-HAND + 1 LEFT-HAND with:<> Entry conveyor with liftable polycord, H. 1350mm; for packages up to 1000mm;<> Adjustable equalizer with automatic belt shifting;<> Tilting head with self-regulated descent on the tilting mechanism;<> Quick blade replacement with couplings;<> Quick fork replacement;<> Pressure release on the tilting mechanism at the beginning of the package;<> Copy ribbing at the output, adjustable in movement;<> Automatic package movement with a top-holding device during transfer between the stacking and strapping areas ("hands");<> Filispot with bundling,<> DENEX copy counter preparation;<> Allen Bradley PLC;<> 2nd and 5th upper belts movable;<> Include a system for double parallel strapping to be used with "Double Digest" format;<> Modem;<> Motors for format change adjustment.<>2 x Denex copy counters <>1 x Automatic loading of boards with a translating arm<> Roller conveyor under the board loader<>2 x Top-fix with self-regulating descent sensor<> Ultrasonic sensor<>2 x OMS RT 14 strapping machine with double spool holder for sizes<>2 x Front containment of the package<>2 x Staircase and platform<>2 x Motorized roller conveyor. L620mm<>1 x Automatic tilter for PL with back conveyor:<> with motorized rollers and automatic tilting;<> package discharge to the rear;<> with interlocked door for front machine access;<>3 x Package conveyor L. 1320mm<>1 x PL 86 DUAL palletizer with: <> 2 axis of motion (Z, X) and parcel x rotation;<> structure length 4800mm;<> for packs of 1000;<> manual pallet loading;<> side pallet loading |
Technical details
PRICE: Upon request
Images
