Bookletmaking in one pass, automatic release, smooth butt device, magazine and missing staple control, <>counter, movable staple turner, staple and ring staples in the same stapling head, format change in approx. 1 min! <>On-Line corner stapling. <>Booklet size up to 100 pages (80 g/m² paper)<>Paper formats DIN A5, A4, A3, A3+, SRA3 (and any intermediate format)<>Booklet formats DIN A4, A5, A6 (and any intermediate format)<>Cover cardboard up to approx. 300 g/m²<>Stapling heads 2(option: 4 maximum) with magazine control.<>No adjustment for paper thickness required.<>Stapling head positions in mm 30 x 50 x 80 x 50 x 30<>Staple clincher (movable clincher)<>Staple types Ring staples Ri 26/6<>Staples 26/6, 26/8, 26/8S <>Production capacity up to 2,000 booklets/hour<>Shingle delivery electric, adjustable stroke<>Block stapling on-line, up to 40 sheets<>Connection 230 V, 50 Hz, 300 W<>Weight 109 kg<>Dimensions in mm H 870 x W 610 x D 1270 ( D 560 with folded up stream delivery) <>Front trimmer<>The pressing station before trimming ensures flat brochures with a sharp fold, overhead conveyor belts ensure reliable paper transport even of "thick" booklets. <>Adjustable belt tracking ensures that the booklet is always precisely positioned against the stop, even when the booklet is fed in at an angle, format changeover in 30 seconds.<>Front trimmer<>The pressing station before trimming ensures flat brochures with a sharp fold, overhead conveyor belts ensure reliable paper transport even of "thick" booklets. <>Adjustable belt tracking ensures that the booklet is always precisely positioned against the stop, even when the booklet is fed in at an angle, format changeover in 30 seconds.<>Booklet size up to 100 pages (80 g/m² paper)<>Booklet formats A4, A5, A6 (and any intermediate format), min 10 cm<>Cover everything the Foldnak makes<>Production capacity up to 2,000 booklets/hour<>Connection 230 V, 50 Hz, 600 W<>Weight 160 kg<>Dimensions in mm (H x W x D) H 870 x W 550 x D 1590 ( D960 with folded up delivery
