SITMA C 80/750 from 2004

Automatic Inserting and Polywrapping Line for Printed Materials and Direct Mail<>A high-performance automatic packaging line designed for collating, personalizing, and polywrapping printed materials, magazines, catalogs, direct mail items, and other products.<>The system enables automatic insertion of multiple inserts, application of three-dimensional items, address personalization, labeling, and subsequent packaging in shrink or non-shrink film.<>Main Features<>Automatic feeding of the main product<>Opening of the product under the cover or in the center fold<>Insertion of up to 6 flat (2D) inserts<>Insertion and optional gluing of one three-dimensional (3D) item<>Application of self-adhesive labels<>Printing of two independent addresses on the finished package<>Film wrapping with side-seal or top-seal configuration<>Capability to use pre-printed film with precise registration and cutting<>Film shrinking in a heat tunnel<>Cross-stacking of finished mail pieces<>Packaging Parameters<>Without 3D item<>Minimum size: 130 × 150 mm<>Product thickness: 2–30 mm<>With 3D item<>Minimum size: 175 × 250 mm<>Total package thickness: up to 30 mm<>Maximum 3D item height: 25 mm<>Film Specifications<>Film width: 250–700 mm, depending on sealing configuration<>Film thickness: 13–50 μm (recommended: 22–35 μm)<>Maximum film roll diameter: 600 mm<>Advantages<>Modular design<>High format flexibility<>Integrated personalization, addressing, and packaging<>Capability to insert both 2D and 3D inserts<>Processing of pre-printed films with precise registration and trimming<>SITMA 750 Polywrapping Line<>The SITMA 750 packaging line is designed for automatic insertion of supplements, personalization, application of three-dimensional items, film wrapping, and address printing.
